Ube Model 800 HVSC
New 2001 - Only 275,000 Cycles (prototype work only)
Two Available
Click here for more information

Technical Specifications:	(View in Metric)
Clamping Force:	880 US Tons
Maximum Die Thickness:	37.4 Inches
Minimum Die Thickness:	21.6 Inches
Platen Dimensions (horizontal x vertical):	53.10 x 53.10 inches
Maximum Die Stroke:	29.92 inches
Clearance between tie bars:	33.50 inches
Tie Bar Diameter:	7.00 inches
Shot Cylinder Stroke:	29.9 inches
Shot Velocity (minimum - maximum):	1.2" - 59" inches per second
Clamp Design:	Horizontal Toggle Clamp
Shot Design:	Vertical Docking Shot
Shot Capabilities:	Traditional, squeeze and slurry

Features and Accessories:

Dual Automatic Tie Bar Pulling - Top Two Tie Bars

Traditional, squeeze, slurry and New Rheocast shot capabilities

One Fanuc Six Axis Robot for handling slugs (squeeze, slurry and New Rheocasting)

One Fanuc Six Axis Robot for spraying & extracting castings

Three Core Circuits

Machine Safety Guards and Doors

Hydraulic Bumper Plate Ejection System

UBE RRS-8 Slurry Production Unit

UBE Factory Installed Auto-ladle
