Trim Presses Model QTP-40 One (1) Used Quantum Trim Press 40 Ton Four Column (Post) Vertical Hydraulic Die Casting Trim Press Inventory #: 2851 Condition: Used Sold Quantum Trim Press - QTP-40 40 Ton Four Column (Post) Vertical Hydraulic Die Casting Trim Press, Allen Bradley MicroLogix 1000 Controls used 1
Die Cast Machinery, LLC Inventory number: 2851
We offer for sale, subject to prior sale and the terms listed below:

One (1) Used Quantum Trim Press 40 Ton Four Column (Post) Vertical Hydraulic Die Casting Trim Press

Model QTP-40

Status: Sold
Specifications: Metric / U.S. Standard
Model: QTP-40 / QTP-40
Pressing Tonnage: 36 tons / 40 tons
Number of Columns: 4 / 4
Daylight: 685 mm / 27 inches
Stroke: 457 / 18 inches
Shut Height: 228 / 9 inches
Clearance between Tie Bars (Left to Right): 939.8 mm / 36.8 inches
Clearance between Tie Bars (Front to Back): 698.5 mm / 27.5 inches
Bed Size (Left to Right by Front to Back): 1219 x 965 mm / 48 x 38 inches
Cut out Size in Bed: 635 x 381 mm / 25 x 15 inches
Features & Accessories:
T Slotted Platens
Air Safety Ratchet
Dual Safety Pull-Out Bars
Allen Bradley MicroLogix 1000
One (1) Auxiliary Side Core/Punch Hydraulic Circuit
Automatic Lubrication System
Terms of Sale:
Price: request quotation
Shipping Terms: F.O.B. Warehouse

Expedited International shipping available to the following Countries: India, Germany, France, Spain, Portugal, Switzerland, Italy, England, Sweden, Netherlands, Poland, Turkey, Ukraine, UK, Great Britain, Russia, Australia, Japan, Korea, Thailand, China, Singapore, Canada, USA, Mexico, Brazil, Argentina, Columbia, Venezuela, Peru, Europe, Asia, North America

Description: Used, Quantum Trim Press Model QTP-40 40 Ton Four Column (Post) Vertical Hydraulic Die Casting Trim Press For Sale, Features include: T Slotted Platens, Air Safety Ratchet, Dual Safety Pull-Out Bars, Allen Bradley MicroLogix 1000, One (1) Auxiliary Side Core/Punch Hydraulic Circuit, Automatic Lubrication System, Allen Bradley MicroLogix 1000 Controls, Second Hand, DCM-2851
