Used Ex-Cell-O B&T Model: DC-850 850 Ton Horizontal Cold Chamber Aluminum High Pressure Die Casting Machine


Print PDF

Status: Available

We offer for sale, subject to availability, prior sale and the terms listed below:

Manufacturer: Ex-Cell-O B&T

Model: DC-850

Size: 850 Ton

Inventory Number: DCM-5643

Used Ex-Cell-O B&T Model: DC-850 850 Ton Horizontal Cold Chamber Aluminum High Pressure Die Casting Machine.

View Available Cold Chamber Die Casting Machines

Click above for larger image

Features & Accessories:

  • Rebuilt with Top Helper-side Automatic Tie Bar Puller, Visi-Trak Sure-Shot Closed Loop Servo Shot Control System
  • Allen Bradley SLC 5/03 Controls with PanelView 600 HMI
  • Twin Cylinder Hydraulic Bumper Plate Ejection
  • Electric Motorized Die Height Adjustment
  • Trabon Heavy Oil Type Automatic Lubrication System
Related Categories

Related Brands

Item Specifications for DCM-5643

Specifications
Tonnage:
850 tons
Tie Bar Diameter:
7 inches
Clearance Between Tie Bars:
36.5 inches
Front Platen Size (T x W x H):
14 x 60 x 69 inches
Die Thickness (minimum - maximum):
18 - 38 inches
Die Stroke (Adjustable):
16 - 22 inches
Shot Positions (inserted):
Center, -6, -9
Main Motor Power:
75 hp
Machine Dimensions:
8.5 x 28.5 x 10 feet
Machine Weight:
95,000 pounds

Description

Used, Ex-Cell-O B&T Model DC-850 850 Ton Horizontal Cold Chamber Aluminum High Pressure Die Casting Machine For_Sale, Features Include: Allen Bradley SLC 5/03 Controls with PanelView 600 HMI, Twin Cylinder Hydraulic Bumper Plate Ejection, Electric Motorized Die Height Adjustment, Trabon Heavy Oil Type Automatic Lubrication System, Allen Bradley SLC 5/05 with PanelView 600 HMI controls, second Hand, DCM-5643
