Used VJ Technologies Model: RIX 200kV 200 Peak kV Real Time Industrial X-ray
Status: Sold - View Available
We offer for sale, subject to availability, prior sale and the terms listed below:
Manufacturer: VJ Technologies
Model: RIX 200kV
Size: 200 Peak kV
Inventory Number: DCM-4926
Used VJ Technologies Model: RIX 200kV 200 Peak kV Real Time Industrial X-ray.
Features & Accessories:
- New in August 2018 | Purchase Now for a Fraction of New Cost - CNC Real-Time 200 kV Digital X-Ray Inspection Cell with indexing table and Fanuc seven axis C- Arm Imaging Capture and VJT DRS ADR Software
- Meets international radiation safety standards, including 21 CFR1020.40 and EN 61010-2-091 2012; ASTM Stds. 2597, 2699, 2736, 2737
- Dedicated Computers for Acquisition and ADR (Automatic Defect Recognition)
- Fast cycle time due to dedicate indexing part table - Inspection of parts internally while loading next batch of parts externally
- Upgraded using with 200 kV peak power generator
- Internal Cabinet Surveillance Camera displayed in the Vi3 Software Window
Item Specifications for DCM-4926
| Specifications | |
|---|---|
| Inspection Envelope (diameter x height, measured for the center of the beam) |
18 x 36 x 20 inches
|
| Part Weight |
60 pounds
|
| Door Opening (W x H) |
72 x 22 inches
|
| Radiation Cabinet (W x H x D) |
87 x 97.2 x 151.2 inches
|
| Weight: |
22,000 pounds
|
| X-ray Source: |
200 kV peak
|
| Decector: |
8 inch FPD (X-ray Flat Panel Detector)
|
| Computer #1: |
Dedicated Acquisition Computer
|
| Computer #2: |
Dedicated ADR/Review Computer
|
| Image Capture Manipulator: |
FANUC R-2000iB/165R series robot
|
| Cycle Time: |
<20 seconds per part (4 views)
|
Shipping Terms: Ex-works
We offer same day shipping on many of our products with next day delivery available within the United States in many cases. We can supply both domestic and international export packing using ISPM-15 certified materials. We can arrange contractor services for dismantling, rigging, packing and transportation. Within North America we can ship single pieces weighing up to 182,000 pounds/82,727 kg. We have shipped hundreds of die casting machines internationally up to 4,000 tons.
Description
Used, VJ Technologies Model RIX 200kV 200 Peak kV Real Time Industrial X-ray For_Sale, Features Include: Meets international radiation safety standards, including 21 CFR1020.40 and EN 61010-2-091 2012; ASTM Stds. 2597, 2699, 2736, 2737, Dedicated Computers for Acquisition and ADR (Automatic Defect Recognition), Fast cycle time due to dedicate indexing part table - Inspection of parts internally while loading next batch of parts externally, Upgraded using with 200 kV peak power generator, Internal Cabinet Surveillance Camera displayed in the Vi3 Software Window JVT Vi3 ADE Filter technology and VJT DRS Automated Fault Detection Software controls, second Hand, DCM-4926
See jumbo large photos of this VJ Technologies RIX 200kV
